--- title: Gateway Battery Replacement description: Tips to successfully replace the battery in your Gateway --- [Skip to content](https://support.barntools.com/en/knowledge/gateway-battery-replacement#main-content) English Show submenu for translations [![BarnTools-logo-RGB@3x](https://support.barntools.com/hs-fs/hubfs/%F0%9F%8E%A8%20Branding%20and%20Design%20Assets/Images/Logos/BarnTools%20Logos/BarnTools-logo-RGB@3x.png?width=318&height=50&name=BarnTools-logo-RGB@3x.png)](https://barntools.com/) Open main navigation Close main navigation - English Show submenu for translations Get Answers. Fast. - There are no suggestions because the search field is empty. 1. [Help Center](https://support.barntools.com/en/knowledge?hsLang=en) 2. [Hardware](https://support.barntools.com/en/knowledge/hardware?hsLang=en) # Gateway Battery Replacement ## Tips to successfully replace the battery in your Gateway **\*Important note:** Purchase a replacement battery from BarnTools to ensure that you are putting in the correct type of battery in your gateway   ****Step 1:** Turn off the Gateway and unplug it** **Step 2:** **Remove the face plate of the Gateway** by removing the 6 phillips head screws on the face of the Gateway. You should now see the circuit board of the Gateway.   **Step 3: Locate the battery in the top-center portion of the Gateway and remove the battery.** Push the battery towards the negative end of the battery (side with spring). ![image\_720](https://support.barntools.com/hs-fs/hubfs/image_720.png?width=688&height=413&name=image_720.png)   **Step 4: Insert the new battery** **Ensure the negative end of the battery is on the spring side of the holder.** The battery has a positive end with a "+" and negative end with a "-". The positive side will have a button on it as shown on the right side of the battery pictured below. **![image\_720-1](https://support.barntools.com/hs-fs/hubfs/image_720-1.png?width=362&height=272&name=image_720-1.png)** **Step 5: Screw the face plate back on the Gateway and Power it On.** **Done!** --- See this article for information about the [Gateway's backup battery](https://support.barntools.com/en/knowledge/hc/en-us/articles/4408058829971-does-the-barntalk-system-have-a-battery-back-up-?hsLang=en). If you have any issues or feedback, reach out to our support team via email at [support@barntools.com](mailto:support@barntools.com). call/text 515-272-5122, or call Toll Free at 855-580-0058 during the hours of 8am-5pm CST Monday through Friday - [Getting Started](https://support.barntools.com/en/knowledge/getting-started?hsLang=en) - [General](https://support.barntools.com/en/knowledge/general?hsLang=en) - [Mobile App](https://support.barntools.com/en/knowledge/mobile-app?hsLang=en) - [Hardware](https://support.barntools.com/en/knowledge/hardware?hsLang=en) - [Subscription](https://support.barntools.com/en/knowledge/subscription?hsLang=en) - [Web Portal](https://support.barntools.com/en/knowledge/web-portal?hsLang=en#main-content) - [Web Portal](https://support.barntools.com/en/knowledge/web-portal?hsLang=en#web-portal) [![Chill listening crop-3](https://support.barntools.com/hs-fs/hubfs/BarnTools-logo-RGB@3x.png?width=152&height=24&name=BarnTools-logo-RGB@3x.png "Chill listening crop-3")](https://barntools.com) (515) 220-2727 Copyright © 2026, BarnTools
